Midnite Solar Photovoltaic Combiner - 3-Position, Model# MNPV3
Breakers/fuse holders sold separately
This Midnite Solar Photovoltaic Combiner accepts din rail mount breakers, ensuring compliance with NEC requirements for combiners when more than 2 strings of photovoltaic modules are installed. DC breakers protect wiring from potential fire in the event of module failure. Handles three 150V DC breakers. The U.S.A. Class Rating: ETL listed, Compatible With 150V breakers, Dimensions L x W x H (in.): 10 1/2 x 5 x 3 1/2, Enclosure Type: Injection-molded insulating dead front under aluminum flip-up exterior cover, Accessory Type: Photovoltaic combiner, Capacity: 3-150V breakers, Material Type: Rainproof NEMA 3R aluminum enclosure, Mount Type: WallIncludes positive bus bar, negative bus bar Din rail for breaker mounting Knockouts for electrical connections and lightning arrestor mounting ETL listed for use in the U.S. and Canada; check individual photovoltaic specs for required series fuse (circuit breaker) rating
- Includes positive bus bar, negative bus bar
- Din rail for breaker mounting
- Knockouts for electrical connections and lightning arrestor mounting
- ETL listed for use in the U.S. and Canada; check individual photovoltaic specs for required series fuse (circuit breaker) rating
- Type 3R environmental rating
- Warranty - 5 yrs.
- Made in the USA
Original: $472.00
-70%$472.00
$141.60More Images
Midnite Solar Photovoltaic Combiner - 3-Position, Model# MNPV3
Breakers/fuse holders sold separately
This Midnite Solar Photovoltaic Combiner accepts din rail mount breakers, ensuring compliance with NEC requirements for combiners when more than 2 strings of photovoltaic modules are installed. DC breakers protect wiring from potential fire in the event of module failure. Handles three 150V DC breakers. The U.S.A. Class Rating: ETL listed, Compatible With 150V breakers, Dimensions L x W x H (in.): 10 1/2 x 5 x 3 1/2, Enclosure Type: Injection-molded insulating dead front under aluminum flip-up exterior cover, Accessory Type: Photovoltaic combiner, Capacity: 3-150V breakers, Material Type: Rainproof NEMA 3R aluminum enclosure, Mount Type: WallIncludes positive bus bar, negative bus bar Din rail for breaker mounting Knockouts for electrical connections and lightning arrestor mounting ETL listed for use in the U.S. and Canada; check individual photovoltaic specs for required series fuse (circuit breaker) rating
- Includes positive bus bar, negative bus bar
- Din rail for breaker mounting
- Knockouts for electrical connections and lightning arrestor mounting
- ETL listed for use in the U.S. and Canada; check individual photovoltaic specs for required series fuse (circuit breaker) rating
- Type 3R environmental rating
- Warranty - 5 yrs.
- Made in the USA
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Breakers/fuse holders sold separately
This Midnite Solar Photovoltaic Combiner accepts din rail mount breakers, ensuring compliance with NEC requirements for combiners when more than 2 strings of photovoltaic modules are installed. DC breakers protect wiring from potential fire in the event of module failure. Handles three 150V DC breakers. The U.S.A. Class Rating: ETL listed, Compatible With 150V breakers, Dimensions L x W x H (in.): 10 1/2 x 5 x 3 1/2, Enclosure Type: Injection-molded insulating dead front under aluminum flip-up exterior cover, Accessory Type: Photovoltaic combiner, Capacity: 3-150V breakers, Material Type: Rainproof NEMA 3R aluminum enclosure, Mount Type: WallIncludes positive bus bar, negative bus bar Din rail for breaker mounting Knockouts for electrical connections and lightning arrestor mounting ETL listed for use in the U.S. and Canada; check individual photovoltaic specs for required series fuse (circuit breaker) rating
- Includes positive bus bar, negative bus bar
- Din rail for breaker mounting
- Knockouts for electrical connections and lightning arrestor mounting
- ETL listed for use in the U.S. and Canada; check individual photovoltaic specs for required series fuse (circuit breaker) rating
- Type 3R environmental rating
- Warranty - 5 yrs.
- Made in the USA
