Luxpower 4G Dongle - 72Mbps Maximum Transmission | 2.5dBi Antenna Gain | HDMI External Interface | W/ IP65 Protection Rating

Experience seamless connectivity with the Luxpower 4G Dongle. Boasting an IP65 protection grade, it ensures durability in harsh conditions from -25℃ to 60℃. Easy to install with a screw-fixed setup, this powerhouse operates on 5V and 0.25A, featuring HDMI and RS485/TTL interfaces. With a maximum transmission rate of 72Mbps and a 100m communication distance, it provides robust Wi-Fi access. Equipped with both software and hardware watchdogs, Modbus-RTU and Modbus-TCP protocols, and flexible parameter settings via app or remote server, it’s the ultimate solution for reliable, high-speed internet.

Key Features:

• IP65 Protection Grade: Designed to withstand harsh environments, the Luxpower 4G Dongle boasts an IP65 protection grade, making it dust-tight and resistant to water. This robust protection ensures reliable performance in demanding outdoor and industrial settings, safeguarding the dongle from the elements and extending its operational life.
• Easy and Secure Installation: The Luxpower 4G Dongle is designed for secure and straightforward installation. It is fixed onto the device using screws, ensuring a stable and permanent setup. Operating at a rated voltage of 5V and a maximum current of 0.25A, providing a reliable connectivity solution.
• High-Speed Connectivity: Experience fast and reliable internet access with a maximum transmission rate of 72Mbps. The dongle operates within a frequency range of 2.412GHz to 2.484GHz, offering stable Wi-Fi access. With a communication distance of up to 100 meters, it ensures broad coverage.
• Advanced Communication Interfaces: Equipped with both RS485/TTL local communication interfaces and an HDMI external interface, the Luxpower 4G Dongle offers versatile connectivity options. It supports Modbus-RTU and Modbus-TCP protocols, facilitating efficient and reliable data transmission for industrial and automation applications.
• Intelligent Management and Updates: The Luxpower 4G Dongle features intelligent management capabilities, allowing for parameter settings via app or remote server. Both software and hardware watchdogs ensure smooth operation without interruptions. Firmware updates can be easily performed using local tools, keeping the dongle up-to-date with the latest features.

Product Specifications:

• Size: 86*55*23mm
• Weight: 34g
• Protection Grade: IP65
• Installation: Fixed on the device by screws
• Rated Voltage: 5V
• Maximum Current: 0.25A
• External Interface : HDMI
• Indicator light: 3
• Operating Temperature: -25℃~60℃
• Storage Temperature: -25℃~60℃
• Local Communication Interface: RS485/TTL
• Public Network Access: Wi-Fi
• Baud Rate: 19200bps (Default)
• Working Frequency: 2.412GHz – 2.484GHz
• Maximum Transmission Rate: 72Mbps
• Communication Distance: 100m
• Antenna Gain: 2.5dBi
• Antenna: External Antenna (External of the antenna are optional)
• Watchdog: Software Watchdog + Hardware Watchdog
• Equipment Layer Communication Protocol: Modbus-RTU
• Network Layer Communication Protocol: Modbus-TCP
• Way of Parameter Settings: App/Remote server
• Firmware Update Way: Local tools

Download:

• Download the Datasheet
