Solis (S6-EH1P11.4K-H-US-APST) 11.4kW 600Vdc 240Vac - Residential Hybrid Storage Inverter | W/ 97.6% Efficiency| UL 9540 Certified (Copy)
Solis (S6-EH1P11.4K-H-US-APST) 11.4kW 600Vdc 240Vac - Residential Hybrid Storage Inverter | W/ 97.6% Efficiency| UL 9540 Certified (Copy)
Solis US introduces the groundbreaking S6 hybrid energy storage inverter—certified to IEEE 1547-2018, UL 1741 SA & SB, and SunSpec Modbus standards. This top-tier PV string inverter excels in all-weather conditions, leading the charge for zero-carbon power with 16A per string PV input, four MPPTs, and a rapid <10ms transfer time. With a 10-year warranty, split-phase backup power, and DC to DC battery charging, the S6 packs a punch, delivering a continuous 11.4kW of backup power. SunSpec Modbus certification, the Solis app, and a fanless design guarantee unmatched reliability and adaptability for diverse backup requirements.
Key Features:
- Four MPPTs allows for versatile PV array design
- Maximum PV input current up to 16A per string
- Transfer time is < 10ms for all backed up loads
- Provides split-phase backup power without an external ATR
- Third-party tested and validated for product reliability
- DC to DC battery charging for optimal use of PV generated energy
- Offers all of the smart inverter functions detailed in IEEE 1547-2018
- Generates up to 50A/11.4kW of continuous backup power with just one inverter
- NEC 2017 compliant with multiple integrated PLC transmitter options available
- Utilizes an energy management system that maximizes efficiency and offers multiple operating modes
- Supports generator interconnection and allows the generator to function as the grid source if utility power is lost
- UL 1741 SB certified, California Rule 21 compliant
- High DC:AC ratio of 1.6 for more PV power capacity
- SunSpec modbus certified with the latest SunSpec models
- Multiple working modes to meet different use case scenarios
- Can be used for both whole-home and dedicated loads backup systems
- Reverse DC polarity protection and software-based AFCI detection
- Solis app allows for remote system configuration and firmware upgrading
- Capable of frequency-watt control for interoperability with other smart devices
- Fanless design using convection cooling for lower failure rate and complexity
- UL 9540 certified with multiple battery brands to provide up to 150 kWh of storage capacity per inverter
Product Specification:
- Max. input voltage: 600 V
- Rated voltage: 380 V
- Start-up voltage: 80 V
- MPPT voltage range: 80-520 V
- Max. input current per string: 16 A
- Max. short circuit current per string: 25.6 A
- Number of MPPTs/Number of strings per MPPT: 4/1
- Battery type: Lithium-ion
- Battery voltage range: 120-500 V
- Maximum charge/discharge current: 50 A
- Battery communication: CAN/RS485
